| 1. Label Dimension Specification | |
| length | 52mm |
| Width | 15mm |
| Thickness(inculding liner) | 270μm |
| Thickness(exculding liner) | 210μm |
| Label Spacing | 2mm |
| 2. Material Specification | |
| Substrate | 80g/㎡ glassing paper |
| Surface | 80g/㎡ thick reinforced paper |
| Inductor Side | Aluminun |
| Capacitor | Aluminun |
| Adhesive | Rubber-based, hot melt adhesive |
| 3. Electrical Specifications | |
| Frequency | 8.2MHz ±328KHz |
| Amplitude | Q≥65 |
| Effective Volume | ≥2000cm³ |
| Deactive Strenght | 0.9A/m-1.5A/m |
| Operating Distance | 0.7-0.8M |
| Deactive distance | 10cm-30cm |
| 4.Environmental Specifications | |
| Shelf Life | Two years from date of manufacture when labels are stored between10℃-25℃（50℉-77℉）and 35% to 65% RH |
| Temperature | Maximun storage tenperature not to exceed 50℃(120℉）for 96 hour at 80%RH |
| Humidity | Unaffected by 80% humidity up to 96 hours |
| Application Temperature |
Above 0℃-38℃(32℉-100℉） and 90% RH at the application head Recommended anbient temperature is 15℃-32℃（60℉-90℉） Recommended ambient humidity is 50%-70% |
